Signal control and connection software

Description
Compatible Operating System: MS Windows 10;
Signal Reception, Transformation, and Processing.
Specifications:
Number of Analog-to-Digital Signals: 40;
Number of Digital-to-Analog Signals: 36;
Number of TTL Input Signals: 384;
Number of TTL Output Signals: 192;
Signal Reception Cycle: ≤ 0.05 s;
Signal Output Response Cycle: ≤ 0.05 s;
Signal Processing Cycle: ≤ 0.05 s;
Functions performed:
Continuous reception of signals from signal interface cards. These signals are continuously sampled and converted into digital signals for computer processing;
Interrupt-driven signal reception. These signals are processed upon occurrence of an event and converted into digital signals for computer processing;
Conversion of digital signals to continuous output signals. Digital signals are converted to analog signals for device control;
Conversion of digital signals to intermittent output signals. Digital signals are converted to digital technical signals for device control.
Data Transmission.
Data Transmission Cycle: ≤ 0.05 s;
Communication Data Packaging: Binary Format;
Communication Protocol: UDP/IP;
Functions performed:
Transmission of control signals from control unit, input devices to computer for processing;
Transmission of data from computer to executing devices (screens, electronic boards, clocks, etc.);
Transmission of simulated flight data, including terrain, weather, location parameters, etc.
