Space simulation software

Description
Compatible Operating System: MS Windows 10;
Terrain Simulation
Terrain Simulation Software Module
Processing Cycle: ≤ 0.05 s;
Simulation Display Cycle: ≤ 0.05 s;
Terrain and Terrain Object Database Storage Format: OpenFlight 16;
Terrain Database Base Grid Size: (10×10) ± 15% km;
Functions performed:
Management of terrain data grids for loading and displaying terrain data;
Paging of terrain data grids for high-resolution terrain display;
Simulation management of 3D models of scene objects such as buildings, trees, roads;
Simulation management of terrain surface triangle meshes to ensure accuracy and performance;
Simulation management of model layers at various detail levels to ensure accuracy and performance;
Simulation management of various terrain data sets such as aerial photos, satellite images to create accurate and comprehensive data sets.
Allows users to integrate terrain databases.
Landscape Simulation.
Processing Cycle: ≤ 0.05 s;
Simulation Cycle: ≤ 0.05 s;
Functions performed:
Simulation display of landscapes, objects, 3D terrain;
Simulation display of 3D models of objects;
Simulation management of 3D terrain, objects data.
Allows users to integrate object databases.
Effects Simulation.
Cloud Base Height Range: 200 ≤ Cloud Base Height ≤ 9000 m;
Cloud Top Height Range: 300 ≤ Cloud Top Height ≤ 10000 m;
Cloud Height Variation Level: 100 m;
Processing Cycle: ≤ 0.05 s;
Simulation Cycle: ≤ 0.05 s;
Functions performed:
Simulation of sky images with sun features, clouds;
Simulation of cloud images and effects in flight, including changing shapes, colors, and cloud thickness;
Simulation of rain effects;
Simulation of images and effects of nighttime flying environments;
Simulation of flying through clouds effects.
Helicopter State Simulation.
Processing Cycle: ≤ 0.05 s;
Simulation Cycle: ≤ 0.05 s;
Functions performed:
Simulation of processing parameters of helicopter model, including size, speed parameters;
Transmission and reception of flight parameter information between helicopter simulation computer and central computer;
Processing information about helicopter state, including position, speed, direction, altitude;
Calculation of helicopter flight parameters including position, speed, angle of rotation;
Simulation of helicopter motion in coordinates and states;
Simulation of helicopter motion in hover, displaying helicopter flight parameters in various situations.
Image Control, Projection Integration on Sphere.
Number of Flight Space Simulation Channels: 6;
Management, configuration of projector information: Available;
Management, display of projector frame grids:
Frame Grid Size: ≥ 10×10;
Grid Cell Size: ≤ 1920×1080;
Functions performed:
Management, integration of projector frame grids;
Editing, adjusting geometry, editing frames of projectors;
Edge blending of images between projectors.
Space Synchronization between Screens.
Screen Viewing Field:
Horizontal: ≥ 180 degrees;
Vertical: ≥ 100 degrees.
Image Display Frequency: ≥ 24 Hz;
Full Screen Resolution: ≥ 5000 x 2000 (pixels);
Functions performed:
Management, integration of projector frame grids;
Editing, adjusting geometry, editing frames of projectors;
Edge blending of images between projectors.
